Generally used rubber sheets

Generally used rubber sheets

Generally used SBR sheets are resistant to maximum 60C° temperature hot water and ph 10 alkali solutions.

RS01 type rubber sheet

Resistant to maximum 60C° temperature hot water and to pH 10 alkali solutions.

Technical data:

  • material: IR/SBR
  • density: 1,50 g/cm³
  • hardness: Shore A 60±5 °Sh
  • tensile strength: min. 4 MPa
  • elongation at break: min. 180%
  • colour: black

Production sizes:

  • thickness (mm): 1 - 50
  • width (mm): 900 - 1500
  • length (m): max. 50 based on the thickness
  • insertion (piece): 0-10 based on the thickness

RS06 type rubber sheet

Resistant to maximum 60C° temperature hot water and to pH 10 alkali solutions.

Technical data:

  • material: IR/SBR
  • density: 1,50 g/cm³
  • hardness: Shore A 80±5 °Sh
  • tensile strength: min. 4 MPa
  • elongation at break: min. 150%
  • colour: black

Production sizes:

  • thickness (mm): 1 – 50
  • width (mm): 900 – 1500
  • length (m): max. 50 based on the thickness
  • insertion (piece): 0-10 based on the thickness
